Surface

The box every effect of Axiom draws on: it owns the shape, the tilt and the frame scheduler.

A surface is the box that every visual effect of Axiom Design System draws on. Wrap your element with ax-surface, pick the layers you need in the layers attribute, and shape it with custom properties: corners, edge features, border and tilt. Your content is always on top of the layers.

The Playground (/playground) has every property and many ready-made shapes. Underneath, Shape computes the outline and Typed OM reads the custom properties. This page shows the properties one idea at a time.

Shape properties are not inherited, so set them on the ax-surface element itself. Surfaces only work while they are visible and read their styles only after something changed.

npm install @ax-design/surface

import { register } from '@ax-design/surface';
register();

<script src="https://unpkg.com/@ax-design/surface/build/main.js"></script>
<script>AxSurface.register();</script>

The radius sets every corner. Percentages are relative to the shorter side, and like border-radius, radii that do not fit are scaled down.

The corner shape has the same keywords as the CSS corner-shape property: round, bevel, scoop and notch. Bevel, scoop and notch corners meet the sides in sharp points; the shoulder radius rounds those points.

<ax-surface class="shape" layers="fill">...</ax-surface>

.shape {
  --ax-radius: 30%;
  --ax-corner-shape: scoop;
  --ax-corner-shoulder-radius: 0px;
}

Every corner can have its own radius, shape and shoulder radius, for example --ax-top-left-radius and --ax-corner-top-left-shape. A corner that sets nothing uses the general value.

A corner can also move into the shape. Positive shifts move the corner toward the middle of the shape: shift the top left and the bottom right corners on x and you get a trapezoid or a parallelogram, depending on the two values. Percentages are relative to the width for x and to the height for y. Negative values move the corner out of the box.

.shape {
  --ax-corner-top-left-shift-x: 20%;
  --ax-corner-bottom-right-shift-x: 20%;
  --ax-top-right-radius: 0px;
}

Each side can carry a feature: a bump or a notch. The kind is arc (circular), rect, triangle, trapezoid or cusp. Cusp is two arcs that meet in a point: pointing in it pinches the side, pointing out it makes a pointed arch.

Depth is how far the feature goes: positive values go out of the shape, negative values go into it. Span is its width along the side. At is where its middle sits; sides run clockwise, so the top goes from left to right. This example uses the top side.

.shape {
  --ax-edge-top-kind: arc;
  --ax-edge-top-depth: -20px;
  --ax-edge-top-span: 40%;
  --ax-edge-top-at: 50%;
}

The --ax-edge-* properties without a side set the feature of all four sides. A side that sets its own value, like --ax-edge-top-depth, wins over them.

Sides run clockwise, so the same --ax-edge-at on every side turns each feature the same way around the shape. The result has rotational symmetry, not mirror symmetry. The tip radius rounds the point of a cusp.

.shape {
  --ax-radius: 30%;
  --ax-edge-kind: cusp;
  --ax-edge-depth: -8px;
  --ax-edge-span: 100%;
  --ax-edge-tip-radius: 20px;
  /* A side can still go its own way. */
  --ax-edge-top-depth: -12px;
}

The fill layer paints the inside of the shape with --ax-fill-color and the border with --ax-border-color. The border is as wide on every side as --ax-border-width says, or per side with --ax-border-top-width and its siblings.

Set --ax-tilt-mode and the surface tilts toward the point you press. Absolute sinks the pressed side by the tilt depth, relative tilts it by a number of degrees. The border keeps the same width on screen while the surface tilts. Press the shape to try it.

.shape {
  --ax-fill-color: rgba(255, 255, 255, 0.14);
  --ax-border-color: white;
  --ax-border-width: 2px;
  --ax-tilt-mode: absolute;
  --ax-tilt-depth: 3px;   /* absolute */
  --ax-tilt-factor: 8;    /* relative, in degrees */
}

The layers attribute lists what the surface draws, in order. Your content is on top of all of them. Fill comes with Surface, the others come from their packages: elevation (a shadow that follows the shape), reveal and acrylic.

Put elevation first, so the other layers paint on top of it. Pick a list below. The background of this preview is an image, so the acrylic has something to blur.

import { register } from '@ax-design/surface';
import { registerAcrylicLayer } from '@ax-design/acrylic';
import { registerElevationLayer } from '@ax-design/elevation';
import { registerRevealLayer } from '@ax-design/reveal-highlight';

registerAcrylicLayer();
registerElevationLayer();
registerRevealLayer();
register();

<ax-surface class="shape" layers="acrylic reveal">...</ax-surface>

.shape {
  --elevation-depth: 16;
}

Clip

Add the clip attribute and the content of the surface is cut to its shape, so an image or a video fills a tile of any shape. The cut follows the shape when it changes, and tilts with the content when the surface is pressed.

Without clip the content keeps its own box, and the shape only draws around it.

<ax-surface class="tile" clip layers="reveal">
  <img src="cover.jpg" alt="" style="display: block; width: 100%; height: 100%; object-fit: cover">
</ax-surface>

.tile {
  width: 220px;
  height: 220px;
  --ax-radius: 24%;
  --ax-corner-shape: scoop;
}
